Matter Smart Electric Curtain Track, Motorized Drapery Rod for Apple HomeKit Alexa Google Home, WiFi Automatic System No Hub Needed, 2.0N.m <30dB Quiet Remote Control Rail (4 meters (157.4 inches))

Next-Generation Window Treatment: Matter over Wi-Fi Smart Curtain System Upgrade your home with the SX-X20-M, a motorized curtain track designed with the Matter protocol. This system connects directly to a 2.4GHz Wi-Fi network and supports multiple smart home ecosystems without requiring a separate hub. Technical Data SheetStandardized parameters for system integrationModel Number: SX-X20-M Connectivity Protocol: Matter over Wi-Fi (No Hub Required) Supported Ecosystems: Compatible with Apple Home, Google Home, Amazon Alexa, SmartThings Rated Voltage: 110~240V AC @50/60Hz Rated Current: 0.2A Rated Power: 24W Running Speed: 13 cm/s Motor Technology: Brushless DC Motor (Operating Noise below 30 dB) Rated Torque: 2.0 N.m (Max Load: 60 kg / 132 lb) Protection Level: IP41 Track Construction: 1.3 mm aluminum track with 8-wire steel reinforced belt Installation Height: 92 mm (3.62 in) hidden ceiling design Remote Control: RF 433.92 MHz single-channel group control Motor Dimensions: 82 x 45 x 72 mm (3.32 x 1.77 x 2.83 in) Why Choose Matter?Universal Compatibility: Supports control across different smart home platforms, allowing use within mixed ecosystems.Local Network Control: Operates over the local Wi-Fi network, reducing reliance on cloud-only communication.Simple Setup: Add the device to your smart home network by scanning the QR code on the motor, when supported by the platform app.Customization ServicesCustomizable Length: Any size between 1 and 10 meters can be customized.Installation Method: Default ceiling mount, wall mount installation available.Opening Method: Center opening by default, with left-to-right or right-to-left single-side options.Track Shape: Straight track by default, with optional 90° and 135° curved tracks.Key Operational Features1. Touch Motion & Manual Override When powered on, a manual pull of more than 10 cm activates motor operation. During power outages, the curtain can be opened and closed manually. 2. Resistance Stop Response If resistance is encountered during curtain movement, the motor stops operation automatically. 3. Heavy-Duty Capacity Designed to support large windows and heavy curtain fabrics, with smooth and stable movement under load. Package Includes 1 x Matter motor, pre-assembled track segments, 1 x RF remote, ceiling mounting brackets, screw set, and user manual.

• ZERO-CUT INSTALLATION & PRE-ASSEMBLED PARTS -- Stop wasting time sawing metal tracks or cutting drive belts manually, which often leads to jamming. Our system solves this common market pain point by shipping with pre-assembled track segments. You simply connect the rails using the included joiners and 4 screws. This simplified design guarantees a smooth glide and eliminates the frustration of missing small parts or complex DIY modifications.
• SEAMLESS SMART ECOSYSTEM INTEGRATION -- Experience the future of home automation. With Matter over WiFi support, this curtain system unifies your home. Imagine a "Good Morning" scene where your curtains gently open to let in sunlight while your Apple HomePod plays music and your thermostat adjusts temperature. It breaks down the barriers between different brands, ensuring a stable, lag-free connection directly via your Wi-Fi router.
• TECHNICAL SPECIFICATIONS -- Model: SX-X20-M | Protocol: Matter over Wi-Fi (No Hub Required) | Ecosystems: compatibility with Apple HomeKit, Google Home, Amazon Alexa, Samsung SmartThings | Torque: 2.0N.m | Max Load: 60kg (132lbs) | Noise Level: <30dB | Track Wall Thickness: 1.3mm | Voltage: 110-240V | Speed: 13cm/s | Protection: IP41.
• HIDDEN AESTHETICS & COMPACT PROFILE -- Designed for modern minimalist interiors. The motor and track combination features a slim profile with a total height of just 92mm (3.62 inches). This compact engineering allows the mechanism to be easily concealed within a curtain box or behind the fabric headers, delivering a clean, professional look that enhances your room's decor without visual clutter.
• MATTER SCAN-TO-CONNECT & APP CONTROL -- Connectivity is now effortless. Simply scan the on-device QR code using your preferred App (compatibility with Apple Home, Google Home, Alexa, or SmartThings) to connect instantly over Wi-Fi. No proprietary gateway or extra hub is needed. You can control your curtains remotely from anywhere, checking their status on your phone to ensure privacy when you are away from home.
• HANDS-FREE VOICE COMMAND -- Enjoy true convenience without lifting a finger. As a Matter-certified device, it offers native compatibility with Siri, Google Assistant, Amazon Alexa, and Samsung Bixby. Whether you are cooking with messy hands or lying in bed, a simple command like "Hey Siri, open the living room curtains" provides instant control.
• GROUP CONTROL REMOTE -- Includes a dedicated 433.92MHz RF remote. Please note: This is a single-channel remote designed for unified management. It can be paired with up to 15 different curtain motors simultaneously, allowing you to synchronize all windows in a large room or open-plan floor to open or close together with a single button press.
• INTELLIGENT SCHEDULING & AUTOMATION -- Automate your natural lighting. Custom time schedules allow the curtains to operate independently, or sync with local sunrise and sunset times for energy efficiency. This feature helps insulate your home by closing drapes during the hottest part of the day and waking you up naturally with sunlight in the morning.
• MANUAL OVERRIDE & SAFETY STOP -- Engineered for everyday life. If power is lost, the system functions as a smooth manual curtain track. When powered, a gentle hand pull of 10cm activates the "Touch Motion" feature to finish the job automatically. For safety, the motor stops instantly if it detects an obstruction, protecting children, pets, and the fabric from damage.
• HEAVY-DUTY BUILD & QUIET MOTOR -- Built to last. The track is constructed from 1.3mm thick aluminum, reinforced by a belt with 8 internal steel wires. Powered by a high-torque (2.0N.m) brushless motor, it effortlessly moves loads up to 60kg while maintaining a whisper-quiet operation below 30dB. We stand by this durability with a comprehensive 5-year warranty.
